Residential Water Supply From Deep Wells
Municipal And Industrial Waters Supply
Irrigation And Other Agricultural Applications
Fire Fighting Systems
Pressure Boosting In HighRise Buildings And Other Applications

WATER FILLED ELECTRIC SUBMERSIBLE MOTORS OF THE REWINDABLE TYPE
•    6” range from 5,5HP to 50HP
•    8” range from 30HP to 125HP
•    10” range from 100HP to 250HP
•    Full stainless steel motor versions available on request
•    Customized winding at 380V, 400V / 50 Hz.

•    Motor protection: IP68
•    Rewindable class F insulation
•    Voltage tolerance: +/- 10%
 •    Winding: PP (Polypropylene) for temp. up to 80°C
•    Cable: 3 core PVC Flat cable + separate earth cable
•    Coolant liquid: water + antifreeze coolant
(storage temp. until -15°C)
•    Coupling: Nema standard for 6” and 8” - Specific connection design on request for 10”
•    Rotation sense: bi-directional
 •    Starts per hour:10
•    Installation: vertical/horizontal
•    Ready for VSD operation
•    Winding for higher temp.: Pe2+Pa (on request)
•    Thermal probe: PT100 thermal fitted inside (on request)
